FMS-CS1500
PREVENTIVE MAINTENANCE
MAXIMUM EFFICIENCY
DESCRIPTION
The Contamination Sensor CS1500 is used to continuously monitor the particle contamination in fluids. The cleanliness class results can be displayed according to ISO/SAE or ISO/NAS classifications. Using the latest technologies, combined with more than 20 years of tried-and-tested engineering, we can now provide the user with a small and robust sensor. Thanks to the new digital interface, operating the sensor with mobile devices is easy and intuitive. The field of application is now also being expanded with new industry standard communication interfaces.
TECHNICAL SPECIFICATION
| Smart Features | ∙ Last 10 events displayed as histogram on digital user interface
∙ Adaptive measuring cycles for very clean fluids and changing measuring conditions ∙ Continuous self-diagnosis with fault indication via LED, display and a digital interface |
| Digital Interface | ∙ Wireless configuration and control via smartphone
∙ Visualization of measured data and sensor status ∙ Cleanliness limit assistant ∙ Creation of reports in PDF format |
| Display (only for CS152X) | LED, 6 digits, 17 segments each |
| Measured Variables | ∙ ISO classes (>4 μm >6 μm >14 μm >21 μm) only ISO code in the display (>4 μm >6 μm >14 μm) SAE (SAE AS 4059) or
∙ ISO classes (>2 μm >5 μm >15 μm >25 μm) only ISO code in the display (>2 μm >5 μm >15 μm) NAS (NAS 1638) |
| Service Variables | ∙ Flow in ml/min ∙ Drive (%) ∙ Temperature (°C or °F) |
| Installation Position | No restrictions (recommended: vertical flow direction) |
| Ambient Temp. Range | -30 °C to 80 °C / -22 °F to 176 °F |
| Storage Temp. Range | -40 °C to 80 °C / -40 °F to 176 °F |
| Relative Humidity | Max. 95 %, non-condensing |
| Sealing Material | ∙ CS15X0: FPM ∙ CS15X1: EPDM |
| Protection Class | III (safety extra-low voltage) IP67 (with screw-in connector) |
| Weight | 1.3 kg |
| Measuring Range | From 20 to 32,000,000 particles per 100 ml, corresponding to ISO class 4 to 25 |
| Accuracy | +/- 1/2 ISO class in the range ISO13/11/10 to 23/21/18 |
| Operating Pressure | Max. 350 bar / 5075 psi |
| Hydraulic Connection | Pipe or hose connection (A,B): thread G1/4, ISO 228 or flange connection (C,D): DN 4 |
| Permitted Measurement Flow Rate | 30 to 500 ml/min |
| Permitted Viscosity Range | 1 to 1000cSt (32 to 4635 SUS) |
| Fluid Temperature Range | 0 to 85 °C / 32 to 185 °F |
| Supply Voltage | 24VDC +/-10%, residual ripple <10% |
| Power Consumption | 5W plus connected loads – switching output / analogue output |
| Connection Plug | ∙ Plug-in connector M12x1, 8-pin, male, in accordance with VDE0627 or IEC61984
∙ Plug-in connector M12x1, 5-pin, male, in accordance with VDE0627 or IEC61984 |
| Ethernet Interface | ModBus TCP, HTTP |
| RS485 (2-wire) | ModBus RTU or HSI (HYDAC proprietary protocol) |
| HSI (single wire) | HYDAC proprietary protocol |
| Analogue output (2-conductor technology) | 4 to 20 mA output (active): max. load of 500 Ω Accuracy: ± 1 % FS |
| Switching output | p-, n-switching or push-pull, parameterisable, switching current < 300 mA |
FEATURES AND BENEFITS
- Early detection of critical machine conditions
- Continuous oil condition monitoring
- Condition-based maintenance planning
- Straightforward operation & integration into industrial control systems
- Safe operation thanks to smart features such as turbidity detection (beta validation)
- Rapid creation of measurement reports
- Price-performance ratio
