FMS-1/25-PSCB

DESCRIPTION

Particle contamination control is essential for protecting fuels and industrial fluids. Our filter elements provide reliable protection for diesel fuels, lubricating oils, and hydraulic systems, helping maintain cleaner, safer, and more efficient operations.

Water and emulsions negatively affect the performance of fuels and lubricating oils, causing corrosion, oxidation, and reduced efficiency. Our absorbent elements help keep fluids free of moisture, protecting hydraulic equipment, lubrication systems, and critical diesel applications.

1/25-PSCB TECHNICAL SPECIFICATION
Efficiency Beta 4>4193 (ISO 16889:99)
Theta 4>4310 (SINGLE PASS)
Dirt Holding Capacity (DHC) 140 grams (MTD)
Recommended Flow Rate 25 gpm (TRANSFER)
Maximum Flow Rate 50 gpm (RECIRCULATION)
Maximum Pressure 100 psi
Housing Bowl FMS-25-BW

W25-ASCB TECHNICAL SPECIFICATION



Efficiency 95%
Water Holding Capacity (WHC) 1000 ml
Recommended Flow Rate 25 gpm (TRANSFER)
Maximum Flow Rate 40 gpm (RECIRCULATION)
Maximum Pressure 100 psi
Housing Bowl FMS-25-BW
